5. External Dimensions and a Sample Foot Pattern
55.0
21.8
40
.0
5.
3
16
.5
40
a
40
b
1a
1b
40
21
20
1
41
60
61
80
40
a
40
b
1a
1b
CN
1
CN
2
…
………
…
………
…
…
…
…
0.25
0.5
14.0
10.0
14
.0
10.
0
M3T-F160-64NSD
REV.A
MADE IN JAPAN
I C1
Figure 3 External dimensions and a sample foot pattern of the M3T-F160-64NSD
6. Precautions
CAUTION
Caution to Be Taken for This Product:
When connecting the YQPACK064SD, be sure to use the included YQ-GUIDE's.
Do NOT use the screws included with the YQPACK064SD for connecting the YQPACK064SD.
IMPORTANT
Notes on This Product:
We cannot accept any request for repair.
For purchasing the NQPACK064SD-ND, YQPACK064SD, HQPACK064SD, contact the following:
Tokyo Eletech Corporation
http://www.tetc.co.jp/e_tet.htm
Daimaru
Kogyo
Ltd.
http://www.daimarukogyo.co.jp/
For inquiries about the product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage
http://www.renesas.com/en/tools
