OPERATION
CLEARING A JAMMED FASTENER
See Figure 10.
WARNING:
Disconnect the tool from the air supply before
clearing a jammed fastener. Failure to do so could
result in serious personal injury.
If a nail or fastener becomes jammed in the tool, disconnect
the air hose and keep the tool pointed away from you while
clearing the jam.
n
�Open magazine and remove fasteners from the tool.
n �Pull up on the latch and open the jam release.
n Insert a flat blade screwdriver into the driving mechanism
and push the driver mechanism back, freeing the fastener
jam.
n Remove the bent fastener.
n Close the jam release and latch.
n Reconnect the tool to the air supply.
n Reinstall fasteners and close the magazine.
Fig. 10
LATCH
JAM
RELEASE
