Raymarine RAYTHEON E32002 User Manual
Page 10
Raystar 112LP GPS Transducer Installation
Raytheon Raystar 112LP GPS Receiver
Mounting Template
Cable Exit Channel
18mm
(0.7in)
6mm (0.25") dia.
for cable only
19mm (0.75") dia.
for NMEA plug
6mm (0.25") dia.
2 positions
18mm
(0.7in)
36mm (1.4in)
36mm (1.4in)
D4194-1
Note:
Access to the underside of the mounting surface must be available to allow for
secure fixing.
