RedMax BT2200LDC User Manual
Page 21
Fig.5 ENGINE GROUP FOR BT2200LDC. BC2200E. BC2200LDC.HE2200LDC
Key#
Description
Part Number
Q'ty
Key#
Description
Part Number
Q'ty
1
Cylinder
5850-12110
1
2
Gasket, base
5500-12211
1
3
Bolt
1850-12130
2
4
Insulator
5850-13160
1
5
Gasket, insulator
5850-13120
1
6
Gasket, carburetor
5850-13130
1
7
Screw
5850-13210
2
8
Muffler ass'y
5850-15100
1
10
Arrester
5850-15140
1
11
Screw
5850-15130
2
12
Gasket, muffler
5850-15211
1
13
Plate, muffler
5850-15220
1
14
Screw
5850-15230
1
15
Crankcase comp
5850-21100
1
16
Gasket, case
5500-21140
1
17
Bearing
06030-06001
2
18
Oil seal
2169-21210
1
19
Oil seal
1850-21220
1
20
Snap ring
04065-02812
1
21
Screw
01252-30530
4
22
Piston
5600-41111
1
23
Ring
1100-41210
2
24
Pin
1101-41310
1
25
Snap Ring
1260-41320
2
26
Crankshaft comp
5850-42000
1
27
Key
1000-43240
1
28
Shoe-c
5850-51100
1
29
Washer
5850-51210
1
30
Spacer
5850-51220
1
31
Rotor
5850-71111
1
32
Coil ass'y
5850-71200
1
33
Spacer
1260-71261
2
34
Screw
5850-72160
2
35
Recoil ass'y
5850-75100
1
36
Case comp.
5850-75110
1
37
Reel
5850-75120
1
38
Spring, spiral
5850-75130
1
39
Screw
5850-75140
1
40
Washer
1400-86280
1
41
Rope
5850-75150
1
42
Knob
5850-75160
1
43
Pulley ass'y
5850-75200
1
44
Ratchet
5850-75220
1
45
Spring
5850-75230
1
46
Ring
0308-00040
1
47
Screw
5850-15230
4
48
Bracket
5850-83221
1
49
Carburetor ass'y
5850-81000
1
50
Screw
5850-81110
2
51
Ring
1751-81130
1
52
Swivel
1881-81140
1
53
Valve ass'y
—————
1
54
O-Ring
1751-81240
1
55
Jet
5516-81250
1
56
Diaphragm
3310-81260
1
57
Gasket, pump
1065-81410
1
58
Diaphragm, pump
1065-81420
1
59
Body, pump
1850-81450
1
60
Screen
3306-81380
1
61
Gasket, diaphragm
1850-81470
1
62
Body, purge
1850-81490
1
63
Pump, priming
1751-81510
1
64
Cover, pump
1850-81520
1
65
Screw
1850-81530
4
66
Screw
5850-82310
2
67
O-Ring
5850-83110
1
68
Body ass'y
5850-82100
1
69
Sleeve
—————
2
70
Plate, choke
—————
1
71
Lever, choke
—————
1
72
Screw
—————
1
73
Element
5850-82170
1
74
Cover
5850-82210
1
75
Housing comp
5850-31100
1
76
Bolt
0225-30635
1
77
Nut
0280-10605
1
78
Screw
5850-13210
4
79
Cover, engine
5850-32110
1
80
Screw
5850-15230
1
81
Screw
5850-32170
2
82
Spark plug
5602-73110
1
83
Switch comp
5850-72210
1
84
Tank
5850-85110
1
85
Cap ass'y
5850-85200
1
86
Pipe, Return
5850-85320
1
87
Grommet
5850-85330
1
88
Filter ass'y
5850-85400
1
89
Screw
5850-85510
3
90
Label, recoil
5850-91120
1
91
Tool set
5850-91000
1
92
Socket
3239-91310
1
93
Bar
3582-91330
1
94
Bar
3540-91110
1
