Attach the left and right hoods to the monitor
Note
• Be sure to install the second hood only after the other hood is firmly attached with hook.
1
Attach the top side of the left hood to the monitor first and then securely fit the
left side of the hood in order to fix the hood to the monitor.
2
Insert the hook into the hole under the projection on the back side of the monitor
(1) and slide it down (2).
3
Attach the right hood in the same way.
4
Attach the left and right hoods to the monitor with the metal fitting.
5
Check the locations of the depressions in the fitting and insert the fitting into the
left and right hoods by aligning those depressions with the projections ( ) in the
grooves on the right and left hoods.
Insert into the hole
under projection
