NetComm 4-port and 8-port Gateways Gateway Series - Manual (Page 37)

SmartVoice Gateway(s) User Guide 37
YML83 Rev
Advanced Options
NOTE: There are two levels to enter Web. Administrator is able to change all
settings. Web UI only changes some settings.
• Administrator’s name and Password: Enter administrator name and password, which has the
highest level of control of the gateway.
• Web UI Login ID and Web UI/IVR Password: Enter login ID and password when you log into the
Web interface/IVR of the gateway as a normal user.
• Web UI auto log out: If a user does not act within the effective time range when logging into the
web interface, the user will be disconnected from the web page to allow others to login.
• Dial Wait Timeout: Use it to set the waiting time for the user’s first key pressing when dialing a
number. The user will hear a busy tone if he/she does not press the first key within the set time
frame.
• Inter Digits Timeout: Set the waiting time between each key pressing. The entered numbers will
be dialed after the timeout.
• Minimum DTMF ON Length (Dial on)/ Minimum DTMF OFF Length (Dial off - between
tones): Used to set dial tone when a call is being diverted to another extension.
• DTMF Detection Sensitivity: Used to adjust the sensitivity of the telephone keys.
• Enable Out-of-Band DTMF: To send DTMF keys (0~9, *, #,) follow the RFC833 rules or via SIP
Info.
NOTE: Out-of-Band DTMF transport method may vary with different VoIP networks,
please contact your VoIP provider for their preferred method.
NOTE: The 800 series gateway has three extra options compared to the 400
series gateway: FXO Dial Type, FXO Impendance and FX Impedance. Use the
default settings for these options as they have been configured for the Australian
telephone network.
