User’s Manual U14337EJ1V0UM00
11
Option board
(IE-703040-MC-EM1)
By adding this board, the IE-703002-MC can be used as in-circuit
emulator for V850/SV1.
Extension probe (SC-176SD Note 1 ) General-purpose extension probe made by TOKYO ELETECH
CORPORATION
PC interface board
IE-70000-xx-IF-B
IE-70000-xx-IF-C
IE-70000-PCI-IF
IE-70000-CD-IF-A
This board is used to connect the IE-703002-MC to a personal computer.
This board is inserted in the expansion slot of the personal computer.
xx: 98 (for PC-9800 series C bus) Note 2
PC (for IBM PC/AT™ or compatibles ISA bus) Note 2
IE-70000-PCI-IF: for PCI bus
IE-70000-CD-IF-A: for PCMCIA socket
Network module
(IE-70000-MC-SV3)
This module is used when a workstation controls the IE-703002-MC via
Ethernet™.
Power adapter
(IE-70000-MC-PS-B)
AC adapter for in-circuit emulator made by NEC Corporation.
Optional hardware
CHAPTER 1 OVERVIEW
The IE-703040-MC-EM1 is an option board for the IE-703002-MC in-circuit emulator. By connecting the IE-
703040-MC-EM1 and IE-703002-MC, hardware and software can be debugged efficiently in system development
using the V850/SV1.
In this manual, the basic setup procedure and switch settings of the IE-703002-MC when using the IE-703040-MC-
EM1 are described. For the names and functions of the parts of the IE-703002-MC, and for the connection of
elements, refer to the IE-703002-MC User’s Manual (U11595E).
1.1 Hardware Configuration
Notes 1. For further information, contact Daimaru Kogyo Co., Ltd.
Tokyo Electronics Department (TEL +81-3-3820-7112)
Osaka Electronics Department (TEL +81-6-6244-6672)
2. Cannot be used for PC98-NX series
Optional hardware Optional hardware
In-circuit emulator (IE-703002-MC)
