7
4. Slide the Press Frame (102) through the Seat Frame
(106).
Press a 2” Square Inner Cap (112) into the indicated
end of the Press Frame (102). Press a 2” Square
Angled Cap (126) onto the other end of the Press
Frame. Make sure the Support Plate (135 [not
shown]) is inside of the 2” Square Angled Cap.
6
124
136
Lubricate
104
105
101
118
7. Lubricate two 3/8” x 3 1/4” Bolts (124). Attach the
Press Plates (108) to the Rear and Forward Press
Uprights (104, 105) with the Bolts and two 3/8” Nylon
Jam Nuts (122). Do not over tighten the Bolts; the
Press Uprights must be able to pivot freely.
7
124
108
108
104
105
6. Press the 2” x 3” Inner Cap (136) into the end of the
Press Base (101).
Lubricate two 3/8” x 3 1/4” Bolts (124). Attach the
Rear and Forward Press Uprights (104, 105) to the
Press Base (101) with the Bolts and two 3/8” Nylon
Locknuts (118). Note: The Rear Press Upright has
an extra hole halfway down the side. Do not over-
tighten the Bolts; the Press Uprights must be
able to pivot freely.
Press two 2” Square Inner Caps (112) into the Rear
and Forward Press Uprights (104, 105).
4
129
126
102
106
112
5. Attach the Press Frame (102) to the Press Base (101)
with four 3/8” x 3” Carriage Bolts (115) and four 3/8”
Nylon Locknuts (118).
5
115
118
102
101
115
118
112
122
Lubricate
