Napoleon Fireplaces GE38NT-M - Manual (Page 24)

24
W415-0429 / C / 11.04.05
GD220 (5 FT)
# PART NO. DESCRIPTION
37* W010-0397 4" FLEXIBLE ALUMINIUM LINER - (5 FT ) C / W SPACERS
37* W410-0017 7" FLEXIBLE ALUMINIUM LINER - (5 FT )
GD330 (10 FT)
# PART NO. DESCRIPTION
37* W410-0018 7" FLEXIBLE ALUMINIUM LINER -(10 FT )
37* W010-0300 4" FLEXIBLE ALUMINIUM LINER -(10 FT ) C / W SPACERS
38* W010-0370 WALL SUPPOR T ASSEMBLY
39 PERISCOPE - GD201
40 WALL TERMINAL KIT - GD222
41 1/12 TO 7/12 PITCH - GD110
42 8/12 TO 12/12 PITCH - GD111
43 FLAT ROOF - GD112
PART NO. DESCRIPTION
44 W010-0569 AIR TERMINAL
45 W120-0036 VERTICAL CAP
46 W170-0063 STORM COLLAR
47 W010-0567 ROOF SUPPORT
48 W263-0054 / W263-0055 / W263-0056 ROOF FLASHING
# PART NO. DESCRIPTION
49* W175-0001 4" COUPLER
49* W175-0013 7" COUPLER
50 GDLVK LOUVRE KIT - UPPER & LOWER - BLACK
50 GDLVPB LOUVRE KIT - UPPER & LOWER - POLISHED BRASS
50 GDLVSS LOUVRE KIT - UPPER & LOWER - BRUSHED STAINLESS STEEL
50 GDLVG LOUVRE KIT - UPPER & LOWER - GOLD
51 L38K LOUVRE KIT - UPPER & LOWER - BLACK
52* W573-0008 HI-TEMPERATURE SEALANT
53* W690-0001 MILLIVOLT THERMOSTAT
54* W500-0163 FIRESTOP SPACER (RIGID VENTING)
55 GD501 HEAT GUARD
56* W585-0096 SOFFIT HEAT SHIELD
57* W010-0810 WALL SUPPOR T ASSEMBLY
58* W175-0170 DURA-VENT ZERO CLEARANCE ADAPTOR
59 W170-0086 VENT PIPE COLLAR
60 W585-0092 VENT PIPE SHIELD
65* W175-0223 CONVERSION KIT - NG TO LP
65* W175-0224 CONVERSION KIT - LP TO NG
66 D70K BLACK DOOR
66 D70G GOLD DOOR
66 D70SS STAINLESS STEEL DOOR
# PART NO. DESCRIPTION
1 W135-0214 LEFT REAR LOG (#1)
2 W135-0216 RIGHT REAR LOG (#2)
3 W135-0184 LEFT MIDDLE LOG (#3)
4 W135-0185 RIGHT MIDDLE LOG (#4)
5 W135-0215 LEFT CROSSOVER LOG (#5)
6 W135-0217 RIGHT CROSSOVER LOG (#6)
7 GL-645 LOG SET
8* W361-0016 GLOWING EMBERS
9* W550-0001 CHARCOAL EMBERS
10* W300-0077 GLASS CRYSTAL EMBERS
11 W357-0001 PIEZO IGNITER
12 W680-0004 THERMOPILE
13 W680-0005 THERMOCOUPLE
14 W010-0800 NATURAL GAS PILOT ASSEMBLY
14 W010-0801 PROPANE GAS PILOT ASSEMBLY
15* W573-0007 HIGH TEMPERATURE SEALANT
16 W455-0070 NATURAL GAS PILOT INJECTOR
16 W455-0068 PROPANE GAS PILOT INJECTOR
17 W725-0044 NATURAL GAS VALVE
17 W725-0045 PROPANE VALVE
18* W385-0245 NAPOLEON LOGO
19* W750-0112 20FT OF WIRE
20 W010-0764 PAN BURNER
21 W455-0040 #41 NATURAL GAS ORIFICE
21 W455-0003 #54 PROPANE GAS ORIFICE
22 W500-0044 FIRESTOP SPACER (FLEX VENTING)
23 W062-0005 BLOWER
24 W660-0030 REMOTE TRANSMITTER
25 W660-0031 REMOTE RECEIVER
26 W010-1168 REAR DOOR ASSEMBLY
27 W300-0074 FLAME EFFECT GLASS
28 W475-0330 DECORATIVE BRICK PANEL - LEFT
29 W475-0331 DECORATIVE BRICK PANEL - RIGHT
30 W010-1090 FLAME EFFECT ASSEMBLY
31 W387-0003 130 VAC T-3 78 MM QUAR TZ LAMP
32 W435-0006 FLAME EFFECT MOTOR
33 W660-0034 ROCKER SWITCH
34 W300-0072 EMBER BED GLASS
35 W300-0073 BURNER DEFUSER GLASS
36 W707-0003 VARIABLE TRANSFORMER
Contact your dealer for questions concerning prices and
availability of replacement parts . Normally all parts can be
ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the follow-
ing information:
1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION O F PART
5. F INISH
FOR WARRANTY REPLACEMENT PARTS
,
A PHOTOCOPY OF THE
ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM
.
REPLACEMENTS
*
IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED
.
FOR
FURTHER INFORMATION
,
CONTACT YOUR NAPOLEON
DEALER
.
REPLACEMENT PARTS
FLEXIBLE VENT KITS
TERMINAL KITS
ACCESSORIES
ROOF TERMINAL KITS
