NTI NODEMUX SERIES UNIVERSAL KVM SWITCH
6
• MAC- Attach a MKTINT-xx-MM cable between the keyboard port of the CPU and a 8 pin miniDIN female "CPU x" port on
the ST-2U switch. Using a 15DM-15HDF adapter, attach a VEXT-xx-MM cable between the video port on the CPU and a
15HD female "VIDEO x" port on the ST-2U switch. (See Fig. 8.)
Figure 8- Connect MAC CPU to ST-2U
• SUN- Attach an SKTINT-xx-MM cable between the keyboard port of the CPU and a 8 pin miniIDIN female "CPU x" port on
the ST-2U switch. Using a 13W3M-15HDF adapter, attach a VEXT-xx-MM cable between the video port on the CPU and a 15HD
female "VIDEO x" port on the ST-2U switch. (See Fig. 9.)
Figure 9- Connect SUN CPU to ST-2U
1 2
4 3
6 5
1 2
4 3
6 5
1 2
4 3
6 5 6
6
6
6
6
6
M A C C P U
V E X T - x x - M M
1 5 D M - 1 5 H D F
M K T I N T - x x - M M
C A B L E A T T A C H M E N T S F O R A M A C C P U
M O N I T O R V I D E O 2 V I D E O 1
8 P i n m i n i D I N M a l e
C o n n e c t o r
4 p i n m i n i D I N M a l e
C o n n e c t o r
1 5 H D m a l e
V i d e o C o n n e c t o r
M a c 1 5 D B M a l e
V i d e o C o n n e c t o r
U S E R C P U 1 C P U 2
9 V D C
. 5 A
- +
1 2
4 3
6 5
U S E R
1 2
4 3
6 5
1 2
4 3
6 5 6
6
6
6
6
6
S U N C P U
V E X T - x x - M M
1 3 W 3 M - 1 5 H D F
S K T I N T - x x - M M
C A B L E A T T A C H M E N T S F O R A S U N C P U
M O N I T O R V I D E O 2 V I D E O 1 1 5 H D m a l e
V i d e o C o n n e c t o r
8 P i n m i n i D I N M a l e
C o n n e c t o r
S u n 1 3 W 3 M a l e
V i d e o C o n n e c t o r
( O r a n g e )
8 P i n m i n i D I N M a l e
C o n n e c t o r
( O r a n g e )
C P U 1 C P U 2
9 V D C
. 5 A
- +
