9.0 Product handling

9.1 Packaging and delivery

Jupiter 20 modules are shipped in Tape and Reel form. The reeled modules are shipped with

250 units per 300 x 44 mm (D x W) reel with a pitch of 32 mm. Each reel is ‘dry’ packaged and

vacuum sealed in an MMB (Moisture Barrier Bag) with two silica gel packs and placed in a

carton.
The MOQ (Minimum Order Quantity) for shipping is 250 units.
All packaging is ESD protective lined. Please follow the MSD and ESD handling instructions on

the labels of the MMB and exterior carton (refer to sections 9.2 and 9.3).

9.2 Moisture sensitivity

The Jupiter 20 GPS receiver is an MSD (Moisture Sensitive Device). Precautionary measures

are required in handling, storing and using such devices to avoid damage from moisture

absorption. If localised heating is required to rework or repair the device, precautionary methods

are required to avoid exposure to solder reflow temperatures that can result in performance

degradation.
Further information can be obtained from the IPC/JEDEC standard J‑STD‑033: Handling,

Packing, Shipping and Use of Moisture/Reflow Sensitive Surface Mount Devices.

9.3 ESD sensitivity

The Jupiter 20 GPS receiver contains class 1 devices and is ESDS (ElectroStatic Discharge

Sensitive). Navman recommends the two basic principles of protecting ESDS devices from

damage:

• Only handle sensitive components in an ESD Protected Area (EPA) under protected and

controlled conditions

• Protect sensitive devices outside the EPA using ESD protective packaging

All personnel handling ESDS devices have the responsibility to be aware of the ESD threat to

reliability of electronic products.
Further information can be obtained from the IEC Technical Report IEC61340‑5‑1 & 2:

Protection of electronic devices from electrostatic phenomena.

9.4 Safety

Improper handling and use of the Jupiter GPS receiver can cause permanent damage to the

receiver and may even result in personal injury.

9.5 RoHS compliance

This product complies with Directive 2002/95/EC on the restriction of the use of certain

hazardous substances in electrical and electronic equipment.

9.6 Disposal

We recommend that this product should not be treated as household waste. For

more detailed information about recycling of this product, please contact your local

waste management authority or the reseller from who you purchased the product.
