Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the following
information:
1. M
ODEL
& S
ERIAL
N
UMBER
OF
FIREPLACE
2. I
NSTALLATION
DATE
OF
FIREPLACE
3. P
ART
N
UMBER
4. D
ESCRIPTION
OF
PART
5. F
INISH
FOR
WARRANTY
REPLACEMENT
PARTS
,
A
PHOTOCOPY
OF
THE
ORIGINAL
INVOICE
WILL
BE
REQUIRED
TO
HONOUR
THE
CLAIM
.
REPLACEMENTS
*
IDENTIFIES
ITEMS
WHICH
ARE
NOT
ILLUSTRATED
.
FOR
FURTHER
INFORMATION
,
CONTACT
YOUR
NAPOLEON
DEALER
.
REPLACEMENT PARTS
ACCESSORIES
#
Part #
Description
1
W135-0260
#1 - REAR LOG
2
W135-0261
#2 - MIDDLE LOG
3
W135-0272
#3 - FRONT LOG
4
W135-0263
#4 - RIGHT LOG
5
W135-0242
#5 - LEFT CROSSOVER LOG
6
W135-0243
#6 - RIGHT CROSSOVER LOG
7
GL653
LOG SET
8
W185-0024
GVFL18 GRATE
8
W185-0020
GVFL24 GRATE
8
W185-0023
GVFL30 GRATE
9
W715-0628
GVFL18 / 24 ANDIRONS
9
W715-0629
GVFL30 ANDIRONS
10
W357-0001
PIEZO IGNITOR AND NUT
11
W455-0078
#31 ORIFICE -
NG
11
W455-0042
#49 ORIFICE -
LP
12
W660-0023
ON / OFF SWITCH
13
W725-0030
VALVE -
NG
13
W725-0031
VALVE -
LP
#
Part #
Description
23*
GD-660
REMOTE WALL SWITCH W/ 20” WIRE
24*
W690-0001
MILLIVOLT WALL THERMOSTAT
25*
W660-0011B
ADVANTAGE PLUS HAND HELD REMOTE
26*
W660-0026
PROGRAMMABLE TIMER
27*
W550-0006
ADDITIONAL LAVA ROCK/CINDERS
14*
W385-0245
NAPOLEON LOGO
15
W662-0003
NATURAL GAS
OXYGEN
DEPLETION
SENSOR
15
W662-0004
PROPANE GAS
OXYGEN
DEPLETION
SENSOR
16*
W010-1321
FIBRE BURNER
17*
W550-0006
LAVA ROCK
18*
W550-0002
CHARCOAL LUMPS
19
W010-1288
DAMPER STOP
20*
W750-0060
IGNITOR CABLE
21*
W720-0084
PILOT TUBE
22*
W135-0265
GVFL30 RIGHT EXTENSION LOG
22*
W135-0266
GVFL30 LEFT EXTENSION LOG
