5. LOGON & LOGOFF
71 71
Closing a Local Web Browser
1.
Close the local web browser.
Select [Exit] under the [File] on the menu bar and close the local web browser. (Or
click the close button on the title bar of the browser.)
Return to the “Terminal Connection Manager” dialog box.
If a dial-up connection is being made, click the active button of the window on the
right of the screen. Clicking the button disconnects the dial-up connection.
2.
Shut down the 630L.
There are three ways to shut down the unit.
• Press the power button. “eClient Shut down” dialog box is displayed. Select
“Shut down”.
• Press the power button. “eClient Shut down” dialog box is displayed. Press the
power button again.
• Press the power button and leave the unit for 20 seconds. The unit
automatically shuts down.
NOTE
• It is possible to Disconnect from a local web server without closing a browser.
