Napoleon Fireplaces BGD40-P - Manual (Page 29)

29
W415-0299 / C / 03.12.03
# PART No. DESCRIPTION
1* W361-0016 GLOWING EMBERS
2* W550-0001 CHARCOAL EMBERS
3 W562-0009 DOOR GASKET (100 INCHES)
4 W010-0454 GLASS W/ GASKET
5* W500-0028 FIRESTOP - FLEXIBLE VENTING
6* W385-0245 NAPOLEON LOGO
7* W573-0008 HIGH TEMP SEALANT
8 GL-634 BGD40 LOGSET
9 W135-0153 LOG#1
10 W135-0154 LOG#2
11 W135-0155 LOG#3 - PIECE A
12 W135-0156 LOG#3 - PIECE B
13 W135-0157 LOG#4
14 W135-0158 LOG#5 - PIECE A
15 W135-0159 LOG#5 - PIECE B
16 W475-0265 END FIBRE BRICK PANEL - FOR WALL
17 W475-0259 END FIBRE BRICK PANEL - FOR BURNER
18 W475-0260 END FIBRE BRICK PANEL - FOR BURNER
19 W475-0261 SIDE FIBRE BRICK PANEL - FOR BURNER
20 W475-0262 SIDE FIBRE BRICK PANEL - FOR BURNER
21 W080-0519 BOTTOM LOUVRE BRACKET
22 W500-0193 BRICK PANEL RETAINER
23 N010-0279 SIDE LOUVRE HOOD W / LOUVRE BRACKETS
24 W200-0114 SIDE DOOR COVER
25 N010-0327 SIDE DOOR HEAT SHIELD
26 W300-0057 END DOOR TEMPERED GLASS ONLY
27 W010-0873 END DOOR TEMPERED GLASS C / W GASKET
3 W562-0009 DOOR GASKET (100 INCHES)
28 W475-0263 SIDE BRICK PANEL - FOR WALL
29 N010-0310 END LOUVRE HOOD W / LOUVRE BRACKETS
30 W500-0192 END BRICK PANEL RETAINER
3 W562-0009 DOOR GASKET (100 INCHES)
16 W475-0265 END FIBRE BRICK PANEL - FOR WALL
31 N010-0326 END DOOR HEAT SHIELD
32 W200-0117 END DOOR COVER
30 W500-0192 END BRICK PANEL RETAINER
33 W010-0516 BLACK SIDE DOOR c/w GLASS
28 W010-0873 END DOOR TEMPERED GLASS
C / W GASKET
33 W010-0516 BLACK SIDE DOOR c/w GLASS
30 N010-0310 END LOUVRE HOOD W / LOUVRE BRACKETS
34 W010-0871 REPLACEMENT BURNER
35 W010-0801 NATURAL GAS PILOT ASSEMBLY
35 W010-0800 PROPANE GAS PILOT ASSEMBLY
36 W455-0069 NATURAL GAS PILOT INJECTOR
36 W455-0067 PROPANE GAS PILOT INJECTOR
37* W660-0005 BURNER ON/OFF SWITCH
38 W680-0004 THERMOPILE
39 W680-0005 THERMOCOUPLE
40 W240-0006 ELECTRODE W / WIRE
41 W357-0001 PIEZO IGNITER
42 N455-0003 MAIN BURNER ORIFICE - PROPANE
42 W455-0072 MAIN BURNER ORIFICE - NATURAL GAS
43 W725-0026 PROPANE GAS VALVE
43 W725-0025 NATURAL GAS VALVE
GD420 (5 FOOT)
44* W010-0772 5" FLEXIBLE ALUMINIUM LINER - (5 FT .) C / W SPACERS
45* W730-0012 8" FLEXIBLE ALUMINIUM LINER - (5 FT .)
GD430 (10 FOOT)
46* W730-0013 8" FLEXIBLE ALUMINIUM LINER -(10 FT .)
47* W010-0773 5" FLEXIBLE ALUMINIUM LINER-(10 FT .) C / W SPACERS
48* W010-0810 WALL SUPPORT ASSEMBLY
49* 1/12 TO 7/12 PITCH - GD410
50* 8/12 TO 12/12 PITCH - GD411
51* FLAT ROOF - GD412
52* W120-0036 VERTICAL CAP
53* W170-0063 STORM COLLAR
54* W010-0453 ROOF SUPPORT
55* W263-0054 /W263-0055 / W263-00056 ROOF FLASHING
56* PERISCOPE - GD401
57* WALL TERMINAL KIT - GD422
REPLACEMENTS
Contact your dealer or the factory for questions concerning
prices and policies on replacement parts. Normally all parts
can be ordered through your Napoleon dealer or distribu-
tor. When ordering replacement parts always give the follow-
ing information:
1. M
ODEL
& S
ERIAL
N
UMBER OF FIREPLACE
2. I
NSTALLATION DATE OF FIREPLACE
3. P
ART
N
UMBER
4. D
ESCRIPTION OF PART
5. F
INISH
6. T OP OR REAR VENT
*
WARNING: This is a fast acting thermocouple. It is an
integral safety component. Replace only with a fast
acting thermocouple supplied by Wolf Steel Ltd.
COMPONENTS COMMON TO ALL UNITS BURNER COMPONENTS
COMPONENTS UNIQUE TO OPEN END UNIT
COMPONENTS UNIQUE TO SEE-THRU UNIT
COMPONENTS UNIQUE TO PENINSULA UNIT
ROOF TERMINAL KITS
TERMINAL KITS
VENT KITS
