Pg 3-5 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
Dimensions
6 -13 VENTING
Vent Lengths
Air Terminal Installation
Venting Application Flow Chart
Typical / Special Vent Installations
Venting Options
14-15 PENINSULA INSTALLATION PROCEDURE
Framing
Bar / Countertop Installation
Brick Panel Installation
Facing
16 OPEN END INSTALLATION PROCEDURE
Framing
Brick Panel Installation
Facing
17 SEE-THRU INSTALLATION PROCEDURE
Framing
Brick Panel Installation
Facing
18 VENT FRAMING DIMENSIONS
19-22 VENTING SPECIFICS
Wall and Ceiling Protection
Horizontal Venting Installation
Vertical Venting Installation
Flexible Vent Components
Fireplace Vent Connection
Rigid Vent Components
Gas Supply Connection
22-25 FINISHING
Mantle Height Locations
Log Placement
Logo Placement
Louvre Installation
Door & Louvre Installation
End Door Installation
26 OPTIONAL BLOWER INSTALLATION
27 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
28 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustments
Restricting Vertical Vents
29-30 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Vent Kits
Terminal Kits
31 ACCESSORIES
32-33 TROUBLE SHOOTING GUIDE
WARNING
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition. Supervise young children when they are in the same room as the
fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fireplace
and venting system are kept clean. The fireplace and its venting system should be inspected before use and at
least annually by a qualified service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. The fireplace area must be kept clear and free from combustible materials,
gasoline and other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to inspect
the fireplace and to replace any part of the control system and any gas control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should be
done by a licensed or qualified service person.
• Do not strike or slam shut the fireplace glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple sup-
plied by Wolf Steel Ltd.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
