Page 29
29
W415-0299 / F / 01.16.07
#
PART No.
DESCRIPTION
1*
W361-0016
GLOWING EMBERS
2*
W550-0001
CHARCOAL EMBERS
3*
W562-0009
DOOR GASKET (100 INCHES)
4
W010-0454
GLASS W/ GASKET
5*
W500-0028
FIRESTOP - FLEXIBLE VENTING
6*
W385-0245
NAPOLEON LOGO
8
GL-634
BGD40 LOGSET
9
W135-0153
LOG#1
10
W135-0154
LOG#2
11
W135-0155
LOG#3 -
PIECE
A
12
W135-0156
LOG#3 -
PIECE
B
13
W135-0157
LOG#4
14
W135-0158
LOG#5 -
PIECE
A
15
W135-0159
LOG#5 -
PIECE
B
16
W475-0516
END FIBRE BRICK PANEL -
FOR
WALL
17
W475-0511
END FIBRE BRICK PANEL -
FOR
BURNER
18
W475-0512
END FIBRE BRICK PANEL -
FOR
BURNER
19
W475-0515
SIDE FIBRE BRICK PANEL -
FOR
BURNER
20
W475-0513
SIDE FIBRE BRICK PANEL -
FOR
BURNER
21
W500-0193
BRICK PANEL RETAINER
22*
W500-0195
RESTRICTOR PLATE
23
W200-0114
SIDE DOOR COVER
24
N010-0327
SIDE DOOR HEAT SHIELD
25
W300-0057
END DOOR TEMPERED GLASS ONLY
26
W010-0873
END DOOR TEMPERED GLASS
C
/
W
GASKET
27
W475-0517
SIDE BRICK PANEL -
FOR
WALL
28
W500-0192
END BRICK PANEL RETAINER
3*
W562-0009
DOOR GASKET (100 INCHES)
16*
W475-0516
END FIBRE BRICK PANEL -
FOR
WALL
29
N010-0323
END DOOR HEAT SHIELD
30
W200-0117
END DOOR COVER
28
W500-0192
END BRICK PANEL RETAINER
31
W010-0516
BLACK SIDE DOOR c/w GLASS
26
W010-0873
END DOOR TEMPERED GLASS
C
/
W
GASKET
31
W010-0516
BLACK SIDE DOOR c/w GLASS
32
W010-0871
REPLACEMENT BURNER
33
W010-0801
NATURAL GAS PILOT ASSEMBLY
33
W010-0800
PROPANE GAS PILOT ASSEMBLY
34
W455-0069
NATURAL GAS PILOT INJECTOR
34
W455-0067
PROPANE GAS PILOT INJECTOR
35*
W660-0005
BURNER ON/OFF SWITCH
36
W680-0004
THERMOPILE
37
W680-0005
THERMOCOUPLE
38
W240-0006
ELECTRODE
W
/ WIRE
39
W357-0001
PIEZO IGNITER
40
N455-0003
#52 MAIN BURNER ORIFICE -
PROPANE
40
W455-0072
#39 MAIN BURNER ORIFICE -
NATURAL
GAS
41
W725-0026
PROPANE GAS VALVE
41
W725-0025
NATURAL GAS VALVE
GD420 (5 FOOT)
42*
W010-0772
5" FLEXIBLE ALUMINIUM LINER - (5
FT
.)
C
/
W
SPACERS
43*
W730-0012
8" FLEXIBLE ALUMINIUM LINER - (5
FT
.)
GD430 (10 FOOT)
44*
W730-0013
8" FLEXIBLE ALUMINIUM LINER -(10
FT
.)
45*
W010-0773
5" FLEXIBLE ALUMINIUM LINER-(10
FT
.)
C
/
W
SPACERS
46*
W010-0810
WALL SUPPORT ASSEMBLY
47*
1/12 TO 7/12 PITCH
-
GD410
48*
8/12 TO 12/12 PITCH
-
GD411
49*
FLAT ROOF
-
GD412
50*
W120-0036
VERTICAL CAP
51*
W170-0063
STORM COLLAR
52*
W010-0453
ROOF SUPPORT
53*
W263-0054 /W263-0055 / W263-00056 ROOF FLASHING
54*
PERISCOPE
-
GD401
55*
WALL TERMINAL KIT
-
GD422
REPLACEMENTS
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the follow-
ing information:
1. M
ODEL
& S
ERIAL
N
UMBER
OF
FIREPLACE
2. I
NSTALLATION
DATE
OF
FIREPLACE
3. P
ART
N
UMBER
4. D
ESCRIPTION
OF
PART
5. F
INISH
COMPONENTS COMMON TO ALL UNITS
BURNER COMPONENTS
COMPONENTS UNIQUE TO OPEN END UNIT
COMPONENTS UNIQUE TO SEE-THRU UNIT
COMPONENTS UNIQUE TO PENINSULA UNIT
ROOF TERMINAL KITS
TERMINAL KITS
VENT KITS
FOR
WARRANTY
REPLACEMENT
PARTS
,
A
PHOTOCOPY
OF
THE
ORIGINAL
INVOICE
WILL
BE
REQUIRED
TO
HONOUR
THE
CLAIM
.
*
IDENTIFIES
ITEMS
WHICH
ARE
NOT
ILLUSTRATED
.
FOR
FURTHER
INFORMATION
,
CONTACT
YOUR
NAPOLEON
DEALER
.
