24
rEc 1, distance 1, azimuth 1, elevation 1,
rEc 2, distance 2, azimuth 2, elevation 1,
rEc 0, distance 0, azimuth 0, elevation 0.
Measurement sets are numbered in reverse order: first
recalled set is the result of the last measurement. If any
parameter has not been actually measured it will not be
recalled.
Pressing A button at any moment within the list of
recalled results brings the unit to Ready to Measure mode.
Choosing cLr at the end of recalled data will erase the
device memory.
5.11 Computer interconnectivity
The unit supports RS-232 interface. Physical connection
is performed through connector with threaded coupling
mechanism, designed for the heavy-duty outdoor
applications.
Do not apply excessive force when disconnecting
cable. Damage to cable or connector resulting from
improper treatment is not covered by warranty.
To attach the cable to the rangefinder match the key on
the plug (1, Fig. 5) with the corresponding key on the
