5.8 Setting interface format

In this mode data communication standard is set. The unit
can output measurement data via RS-232 port in either
PC format (description of the proprietary format can be
obtained from Newcon upon a request) or in the format
accepted by PLGF/DALGR.
To select required data format:


Select PLGr or PC from SEt menu



Pressing Action button will activate PC or PLGR

format, the display name of format that can be
activated will be shown.

5.9 Gating mode

In this mode gating function is activated: here user can set
the minimal distance to the target, any object closer than
the gating distance will be ignored.
To select Gating Mode:


Select GAtE from main menu

Minimal gating distance of 0 meters (display: 000 m) will
be initially set, further pressing M button will increase
gating distance by 100 m up to 3,900 m. When the
desired distance is reached – select it by pressing Action
button.
OVER 100M – indicates that gating is active
