3. Screen Adjustment and Settings
1
-. Color Adjustment
Simple adjustment [CAL Switch mode]
This function allows you to select the best display mode for monitor brightness, etc.
To select CAL Switch mode
Directly pressing allows you to select the best suited mode for screen display from 4 CAL Switch
modes; DICOM-CL, Text, Custom and CAL. Color settings each mode can be adjusted by using the
menu of the Adjustment menu.
Tips
• The Adjustment menu and the CAL Switch mode name cannot be displayed at the same time.
Exit
Press to exit the menu.
CAL Switch Mode
Selectable CAL Switch modes are as follows.
Mode Purpose
DICOM-CL Available for setting tailored to X-ray film color (clear base).
Text Suitable for displaying texts for word processing or spreadsheets.
Custom Available for making desired setting.
CAL Used for monitor calibration
Color Adjustment of the Mode Settings
, and settings can be adjusted on the CAL Switch menu. Select
the desired function icon with
and adjust with Control buttons. (Setting(s) of
and/or is defined as standard default in some modes.
NOTE
• "CAL" mode can be adjusted only by Calibration Software.
->DICOM-CL -> Text -> Custom -> CAL
Current Mode
Mode button Power button
CAL SwitchMenu
Control buttons
[EX.]Custom
Settings status
of Brightness,
Temperature and
Gamma
Enter button
