E – 17
Connecting Your PC Or Macintosh Computer
Connecting your PC or Macintosh computer to your MultiSync MT1020G (XGA) / 820G (SVGA)
LCD Projector will enable you to project your computer's screen image for an impressive presenta-
tion. All of these following display standards are supported:
*indicates that this resolution is supported by MT1020G only.
To connect to a PC, Macintosh or computer equipped with an XGA/SuperVGA/VGA adapter or
compatible graphics adapter, simply:
1. Turn off the power to your LCD projector and computer.
2. If your PC does not support XGA/SuperVGA/VGA you will need to install an XGA/SuperVGA/
VGA graphics board. Consult your computer's owner's manual for your XGA/SuperVGA/VGA
configuration. If you need to install a new board, see the manual that comes with your new
graphics board for installation instructions.
3. Use the MultiCable that's supplied to connect your PC or Macintosh computer to the LCD
projector. For a PC, use the smaller 15-pin connector on the cable to connect to your computer's
video port; use the larger 15-pin connector on the cable to connect to the projector's RGB 1 input.
For Macintosh, use the larger 15-pin connector on the cable to connect to your computer's video
port; use the smaller 15-pin connector on the cable to connect to the projector's RGB 2 input.
(You can also use your own video cable if you wish. For a PC cable, use the smaller 15-pin
connector RGB 2 on the projector. For a Macintosh cable, use the larger 15-pin connector RGB
1 on the projector.)
4. Turn on the LCD projector and the computer.
5. If the projector goes blank after a period of inactivity, it may be caused by a screen saver
installed on the computer you've connected to the projector.
NOTE: Refer to your computer's owner's manual for more information about your computer's video output
requirements and any special identification or configuring your projector's image and monitor may require.
VGA 640
ן480 for graphics
VGA 640
ן400 for graphics
VGA 640
ן350 for graphics
VGA 720
ן400 for text
VGA 720
ן350 for text
SuperVGA 800
ן600
XGA 1024
ן768*
Macintosh at 1024
ן768*
Macintosh at 640
ן480
Macintosh at 832
ן624
