16. Feed the bolt on the High Cable (73) through slot A in
the Top Frame (1) from below.
Attach a 4Ó Pulley (35) to the Top Frame (1) inside
slot A with a 3/8Ó x 2 1/2Ó Bolt (54), two 3/8Ó Flat
Washers (55), two 5/8Ó x 1/2Ó Pulley Bushings (42)
and a 3/8Ó Nylon Jamnut (63).
Fold the High Cable (73) over the 4Ó Pulley (35) you
just installed. Feed the bolt on the High Cable
through slot B in the Top Frame (1) from above.
Wrap the High Cable (73) around a 4Ó Pulley (35).
Attach the Pulley to the Top Frame (1) inside slot B
with a 3/8Ó x 2 1/2Ó Bolt (54), two 3/8Ó Flat Washers
(55), two 5/8Ó x 1/2Ó Pulley Bushings (42) and a 3/8Ó
Nylon Jamnut (63).
Thread the bolt on the High Cable (73) a couple of
turns into the top of the Weight Tube (36) as shown in
the inset drawing.
16
1
42
55
35
35
42
55
54
63 42
63
73
42
55
54
55
Bolt
Slot B
Slot A
73
36
17. The Low Cable (72) is the only remaining Cable. It is
approximately 206Ó long. Note that it has a large ball
on one end and a small ball on the other.
Route the smaller ball on the Low Cable (72) through
the indicated slost in the Leg Lever (29) and the front
leg on the Base (8).
Attach a 4Ó Pulley (35) inside the slot in the front leg
on the Base (8) with a 3/8Ó x 2 1/2Ó Bolt (54), two 3/8Ó
Flat Washers (55), two 5/8Ó x 1/2Ó Pulley Bushings
(42) and a 3/8Ó Nylon Jamnut (63).
18. Attach a 4Ó Pulley (35) inside the slot in the Leg Lever
(29) with a 3/8Ó x 2 1/2Ó Bolt (54), two 3/8Ó Flat
Washers (55), two 5/8Ó x 1/2Ó Pulley Bushings (42)
and a 3/8Ó Nylon Jamnut (63).
Attach the Spacer (83) to the bottom of the Leg Lever
(29) with a 3/8Ó x 2 1/2Ó Bolt (54) and a 3/8Ó Nylon
Jamnut (63).
Press a Tab (84) over the cable cage as shown in the
inset drawing. Note: The Cable (72) must be posi-
tioned as shown.
Press a 2Ó Square Inner Cap (33) into the bottom of
the Leg Lever (29).
Note: It may be easier to attach the Spacer (83)
assembly and the 2Ó Square Inner Cap (33) if you
pull the Leg Lever (29) forward and turn it so that
it is upside down.
17
18
42
63
63
63
54
54
54
29
Front
Leg
29
8
55
33
Slots
Large Ball
42
42
83
84
Cage
42
55
55
55
72
72
35
35
