25
W415-0381 / H / 12.07.07
# PART NO. DESCRIPTION
1 W357-0001 PIEZO IGNITER
2 W680-0004 THERMOPILE
3 W680-0005 THERMOCOUPLE**
4
W010-0800 NATURAL GAS PILOT ASSEMBLY
4 W010-0801 PROPANE GAS PILOT ASSEMBLY
5 W455-0069 NATURAL GAS PILOT INJECTOR
5 W455-0067 PROPANE GAS PILOT INJECTOR
6 W725-0025 NATURAL GAS VALVE
6 W725-0026 PROPANE VALVE
7* W385-0245 NAPOLEON® LOGO
8* W750-0112 20FT OF WIRE
9 W010-0864 PAN BURNER
10 GL-658 LOG SET
11* W361-0016 GLOWING EMBERS
12* W550-0001 CHARCOAL EMBERS
13* W550-0002 CHARCOAL LUMPS
14 W135-0297 REAR LOG (#1)
15 W135-0300 LEFT CROSSOVER LOG (#4)
16 W135-0302 RIGHT CROSSOVER LOG (#6)
17 W135-0298 SMALL LEFT LOG (#2)
18 W135-0299 SMALL RIGHT LOG (#3)
19 W010-1819 BLACK DOOR C / W GLASS
20 W455-0026 #38 NATURAL GAS ORIFICE
20 W455-0003 #54 PROPANE GAS ORIFICE
21* W361-0014 VERMICULITE
22 W010-1778 ADJUSTABLE FIRESTOP
23* W500-0205 RESTRICTOR PLATE
24 W585-0138 VENT HEAT SHIELD, TOP PIECE
25 W655-0222 VENT HEAT SHIELD, BOTTOM PIECE
26 W185-0020 GRATE
** WARNING: THIS IS A FAST ACTING THERMOCOUPLE. IT IS AN INTEGRAL
SAFETY COMPONENT. REPLACE ONLY WITH A FAST ACTING THERMO-
COUPLE SUPPLIED BY WOLF STEEL LTD.
*
GD420 (5 FT)
PART NO. DESCRIPTION
27 W010-0772 5" FLEXIBLE VENT PIPE - (5 FT ) C / W
SPACERS
27 W730-0012 8" FLEXIBLE VENT PIPE - (5 FT )
*
GD430 (10 FT)
PART NO. DESCRIPTION
28 W730-0013 8" FLEXIBLE VENT PIPE - (10 FT )
28 W010-0773 5" FLEXIBLE VENT PIPE - (10 FT ) C / W SPACERS
29 W010-0810 WALL SUPPORT ASSEMBLY
30 PERISCOPE - GD401
31 WALL TERMINAL KIT - GD422
32 1/12 TO 7/12 PITCH -GD410
32 8/12 TO 12/12 PITCH -GD411
32 FLAT ROOF -GD412
PART NO. DESCRIPTION
33 W010-0774 AIR TERMINAL
34 W120-0015 VERTICAL CAP
35 W170-0086 STORM COLLAR
36 W010-0453 ROOF SUPPORT
37 W263-0065 / ROOF FLASHING
W263-0066 /
W263-0067
# PART NO. DESCRIPTION
38* W573-0007 10.3OZ TUBE HIGH TEMP SEALANT
39* W175-0166 5" COUPLER
39* W175-0002 8" COUPLER
40 L42K LOUVRE KIT - UPPER & LOWER - BLACK
40 L42PB LOUVRE KIT - UPPER & LOWER - POLISHED BRASS
40 L42SS LOUVRE KIT - UPPER & LOWER - BRUSHED STAINLESS STEEL
41 GDOI42BG ORNAMENTAL INSET - BRUSHED GOLD
41 GDOI42K ORNAMENTAL INSET - BLACK
41 GDOI42G ORNAMENTAL INSET - GOLD
41 GDOI42SS ORNAMENTAL INSET - STAINLESS STEEL
42* W690-0001 MILLIVOLT THERMOSTAT
43* W660-0010B REMOTE CONTROL - ADVANTAGE
43* W660-0011B REMOTE CONTROL - ADVANTAGE PLUS
44* W660-0013 MODULATING THERMOSTATIC HAND HELD REMOTE
45* GD825N MODULATING VALVE REGULATOR FOR W660-0013 - NG
46* GD825P MODULATING VALVE REGULATOR FOR W660-0013 - P
46 W500-0163 FIRESTOP SPACER (RIGID VENTING)
47 GD501 HEAT GUARD
48* W585-0096 SOFFIT HEAT SHIELD
49* W010-0810 WALL SUPPORT ASSEMBLY
50* W175-0170 DURA-VENT ZERO CLEARANCE ADAPTOR
51 W170-0086 VENT PIPE COLLAR
52 W585-0092 VENT PIPE SHIELD
53 GZ550-1KT BLOWER KIT
54* GD65 FAN KIT
55* GD36 THERMOSTATIC SENSOR CONTROL KIT FOR USE WITH GD 65 ONLY
56* W500-0033 VARIABLE SPEED SWITCH WALL MOUNTING PLATE
57* KB35 VARIABLE SPEED SWITCH
58 GA-566 HOT AIR DISTRIBUTION KIT
59* W690-0005 THERMOSTAT - 110V FOR USE WITH GA-566 ONLY
60* GA-70 EXTENSION KIT - 5 FT
61 GA-72 HOT AIR EXHAUST KIT
62* W175-0211 CONVERSION KIT - NG - LP
62* W175-0212 CONVERSION KIT - LP - NG
63* W500-0397 VERTICAL FIRESTOP
REPLACEMENT PARTS
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor. When ordering replacement parts always give the following
information:
1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
FOR WARRANTY REPLACEMENT PARTS , A PHOTOCOPY OF THE ORIGI -
NAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM .
REPLACEMENTS
FLEXIBLE VENT KITS
TERMINAL KITS
ACCESSORIES
ROOF TERMINAL KITS
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED . FOR FURTHER
INFORMATION , CONTACT YOUR NAPOLEON DEALER .
