E–7
M EN U
E NT ER
CA NC EL SELECT
POWER STATUS
ON /OFF
SOURCE
AUTO ADJUST
Getting To Know Your MultiSync LT84/LT140 Projector
Front Features
M EN U
ENTER
CA NC EL SELECT
POWER
STATUS
ON /OFF
SOURCE
AUTO ADJUST
Lens and Lens Cap
Focus Ring
Zoom Ring
Front Remote Sensor
Rear Remote Sensor
Ventilation (outlet)
Front Adjustable Foot
One-Push Tilt Button
Monaural Speaker (1W)
Lever-Type Adjustable Rear Foot
AC Input
Connect the supplied power
cable’s three-pin plug here.
Front Adjustable Foot
One-Push Tilt Button
Lamp Cover
Bottom Features
Lamp Cover Screw
Ventilation (outlet)
Rear Features
Controls
Terminal Panel
Card Remote Control Slot
The card remote control can be
stored in the cabinet. To insert or
pull out the card remote control, fol-
low the procedures:
Press down to release
Push to insert
