NEC LT84/LT140 - Manual (Page 34)

E–34
M nO 2 - L iCEL L 3 V O
L TS
JA PA
N H
CR2025
MnO
2 - L iCELL 3 V O LT S JA PA N H
CR2025
MnO
2 - L iCELL 3 V O LT S JA PA N H
CR2025
Remote Control Battery Installation
[Wireless Card Remote Control (supplied)]
1. Press firmly and slide the battery cover off.
2. Remove the old Lithium coin cell and install new one (CR2025).
Ensure that the side with a “+” is upward.
3. Put the cover back.
[Full Function Remote Control LT40RT (optional)]
1. Press firmly and slide the battery cover off.
2. Remove both old batteries and install new ones (AA). Ensure that
you have the batteries' polarity (+/–) aligned correctly.
3. Slip the cover back over the batteries until it snaps into place.
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Operating Range
[Wireless Card Remote Control (supplied)]
[Full Function Remote Control LT40RT (optional)]
15˚
5m
3m
15˚
15˚
5m
3m
15˚
30 ˚
7m 7m
30 ˚
30 ˚
30 ˚
