5
Exit Key
Press the Exit key to exit the Help program.
Help Key
Press the Help key. Press desired Soft Key for
helpful information about that key.
MIC (Microphone)
Press the Soft Key below “MIC” to activate or
deactivate the Microphone. LED on Mic key
will illuminate when Mic is on.
DND (Do Not Disturb)
Press the Soft Key to allow denying access to
the station line for incoming calls.
MIC DND >>>
7:35 AM MON 18 JUL 2002
4051
Exit Help
D
EFAULT
F
UNCTION
D
ISPLAYS FOR
E
ACH
S
TATUS
Default Soft Key settings are provided
corresponding to particular functions. Different
Soft Key settings are displayed at the bottom of
the LCD depending on the state of the call, as
shown below.
Different patterns of Soft Key settings can be
registered for individual call states and assigned
to individual terminals as required.
IDLE
DIAL TONE/
DIALING
(1)
(2) FDN FDB >>>
(Time Display)
MIC PICK FDA >>>
(Time Display)
MIC DND >>>
(Time Display)
*NEC-405 NEAX2400 UG #2 1/22/03 2:42 PM Page 5
