70
FACE LAYOUT
1 C ALL I NDICATOR L AMP
Lamp at top corner of Dterm Display flashes when a
call terminates to the terminal. Lamp lights steadily
when a message has been left.
2 LCD(N OTE 1)
Liquid Crystal Diode (LCD) display provides Dterm
activity information plus date, time and Soft Key
Operation. The LCD display has 24-character, 3-line
capability.
3 E XIT
The user can escape from the Help key mode by
pressing this key.
4 S OFT K EYS
Any feature shown at the bottom of the LCD display is
available. The appropriate feature key is displayed on
the screen according to the call handling process.
5 H
ELP
Explanations of the Soft Keys can be called up on the
LCD display by pressing this key.
6 P ROGRAMMABLE K EYS
[Programmable by telephone system administrator
(Flexible Line/Feature Keys)]
• Station line access
• Trunk line access
• Feature access
[Programmable by user (Flexible Line/One-Touch
Speed Dial)]
• Station line access
• Trunk line access
• Feature access
(Note 2)
• Any feature can be assigned.
• Direct station selection
• Station speed dial
7 R ECALL
Press key to terminate established call and return to the
internal dial tone.
8 F EATURE
Used to activate terminal setup functions and to
program One-Touch Speed Dial/Feature Keys.
9 D IRECTORY (N OTE 3)
Press key to activate speed calling – system feature.
10 M
ESSAGE
(N
OTE
3)
Press key to access the voice mail system.
11 M IC
Press key to respond hands free. LED on this key lights
during speakerphone operation.
12 C ONF
Press key to establish a three-way conversation. LED
on key lights when key is active.
13 LNR/SPD (L AST N UMBER C ALL /S PEED C ALLING )
Press key to activate redial feature. Press redial and
scroll back through numbers that have been dialed until
the desired number is displayed. Press the ❉ or # (Note
4) key to activate dialing.
