A-24 / ENGLISH
A-24 - FORM NO. 56041978 - BR1100S / BR1300S
TECHNICAL SPECIFICATIONS (as installed and tested on the unit)
Model BR1100S C BR1300S C
BR1100S BR1300S
Model No. 56413007 56413011
56413006 56413010
Voltage, Batteries V 36V 36V
Battery Capacity Ah 480 480
Protection Grade IPX3 IPX3
Sound Pressure Level (ISO 11201) 76dB LpA, 3dB KpA 76dB LpA, 3dB KpA
Sound Pressure Level (ISO 11201) 72dB LpA, 3dB KpA 72dB LpA, 3dB KpA
Gross Weight lbs / kg 3325 / 1508 3410 / 1547
Transportation Weight lbs / kg 2897 / 1314 2982 / 1353
Gross Weight lbs / kg 3220 / 1460 3320 / 1506
Transportation Weight lbs / kg 2792 / 1266 2892 / 1312
Maximum Wheel Floor Loading (center front) psi / kg/cm 2 116/ 119.9 116/ 119.9
Maximum Wheel Floor Loading (right rear) psi / kg/cm 2 81 / 83.7 81 / 83.7
Maximum Wheel Floor Loading (left rear) psi / kg/cm 2 86 / 88.9 86 / 88.9
Vibrations at the Hand Controls (ISO 5349-1) m/s 2 <1.12m/s 2 <1.12m/s 2
Vibrations at the Hand Controls (ISO 5349-1) Uncertainty m/s 2 .11 m/s 2 .11 m/s 2
Vibrations at the Seat (EN 1032) m/s 2 <0.35m/s 2 <0.35m/s 2
Vibrations at the Seat (EN 1032) Uncertainty m/s 2 0.035m/s 2 0.035m/s 2
Gradeability
Transport
16% (9°) 16% (9°)
Cleaning 10.5% (6°) 10.5% (6°)
revised 6/11
