Part identification chart – NordicTrack NTS79020 User Manual

Page 24

Text mode
Original mode

M10 x 68mm Carriage Bolt (73)

M10 Nylon Locknut (101)

M10 x 70mm Button Head Bolt (87)

M10 x 96mm Button Head Bolt (77)

M10 x 217mm Button Head Bolt (75)

M10 x 46mm Button Head Bolt (76)

M8 Nylon Locknut (102)

M4 x 16mm Screw (95)

M8 x 19mm Button Head Bolt (88)

M8 x 19mm Button
Head Shoulder Bolt (85)

M10 x 25mm Button Head Screw (94)

M10 x 92mm Button Head Bolt (90)

M10 x 82mm Button Head Bolt (74)

M10 x 82mm Carriage Bolt (82)

M8 x 12.5mm Button
Head Shoulder Bolt (83)

1/2" x 76mm Button Head Bolt (84)

1/2" Nylon Locknut (100)

M6 Nylon Locknut (103)

M6 x 50mm Button Head Screw (91)

M6 x 63mm Button Head Screw (92)

M10 Washer (98)

PART IDENTIFICATION CHART

—Model No. NTS79020

REMOVE THIS PART IDENTIFICATION CHART AND PART LIST/
EXPLODED DRAWING. SAVE THIS PART IDENTIFICATION CHART
AND PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE.
