Fault Messages on the EXPRESSSCOPE® Monitor LCD
2-19
Full Name
EXPRESSSCOPE®
Monitor LCD Name Additional Display
Details
Unit Type
(FRU/CRU)
fan module Fan_Modx x =
0 (left module)
1 (right module)
CRU
interconnect cable Intercon_Cablex x =
0 (right)
1 (middle)
2 (left)
FRU
I/O riser board IOR_Brd FRU
PCI expansion card IO_Slotx_y_z x = cell card slot 0 through
5
y = expansion rack 1 or 2
z = expansion rack slot 1
through 5
CRU
voltage regulator
module IPVRMx x = 0, 1, 2, or 3 FRU
main logic module MainLogic_Module FRU
memory board Mem_Brdx x =
0 (left board)
1 (right board)
CRU
DIMM Mem_Brdx_DIMMyy x =
0 (left board)
1 (right board)
yy = 0 through 15
CRU
management board Mgmt_brd FRU
PCIe card PCIe_Slotx x = 0 (bottom) through 5
(top) CRU
RAID controller PCIe_Slot6 FRU
power supply PwrSupplyx x =
0 (left power supply)
1 (right power supply)
CRU
drive tray n/a FRU
DVD drive n/a CRU
hard drive n/a CRU
