Output Requirements
NCR S26 Hot Plug Server User Guide
A-3
Output Requirements
The following represent the output requirements of the 420-watt power
supply:
•
Ripple and noise bandwidth is from DC to 20 MHz.
•
+12V should provide 15 A surge current for the first 10 seconds after
power on, and this regulation should be within ±10%.
•
Total power consumption is 420 watts.
The table below shows the 420-watt power supply output requirements
(measured at output power connector).
Table A-2. 420-Watt Power Supply Output Requirements
Out
-put
Nominal
Regulation
Minimum
Output
Load
Maximum
Output
Load
Ripple
Noise
1
+5 V
+5% to -3%
4.0 A
44 A
50 mV
100 mV
2
-5 V
+10% to -8%
0.0 A
0.5 A
100 mV
200 mV
3
+12 V
+5% to -4%
0.5 A
13 A
200 mV
200 mV
4
-12 V
+8% to -8%
0.0 A
1 A
120 mV
240 mV
5
+3.3 V
+4% to -4%
0.0 A
10 A
50 mV
80 mV
