© National Instruments Corporation

5-1

GPIB-COM User Manual

Section Five
Programming the GPIB-COM

This section presents a description of the GPIB-COM Serial Port Emulator registers and
information on programming the GPIB-COM. You need to use this section only if you are
writing your own serial port device driver.

The GPIB-COM Registers

IBM's serial adapter is a plug-in card for the PC that handles RS-232 communication. The main
component of the adapter is an INS8250 Asynchronous Communications chip or its equivalent,
which is controlled by programming a set of registers on the I/O channel. The names of these
registers and their I/O addresses are given in Table 5-1. Each register is located at a certain offset
from the base address of the board. The addresses are given with an X for the first digit and a Y
for the second digit, where XY=3F for COM1 (base address 3F8), XY=2F for COM2 (base
address 2F8), XY=3E for COM3 (base address 3E8), and XY=2E for COM4 (base address
2E8). Notice that sometimes two registers share the same I/O address. The DLAB bit (bit 7 of
the Line Control Register) determines which register will respond when these addresses are
accessed.

Note: Throughout this section, the term set will be used to mean that a bit is a logical 1, and clear

will mean that the bit is a logical 0.

Table 5-1. GPIB-COM Registers

I/O Address

Offset from

Register

Type

XY=3F for COM1

Base Address

XY=2F for COM2
XY=3E for COM3
XY=2E for COM4

Transmitter Holding Register

write

XY8 (DLAB=0)

0

Receive Buffer Register

read

XY8 (DLAB=0)

0

Divisor Latch LSB Register

read/write

XY8 (DLAB=1)

0

Divisor Latch MSB Register

read/write

XY9 (DLAB=1)

1

Interrupt Enable Register

read/write

XY9 (DLAB=0)

1

Interrupt Identification Register

read

XYA

2

Line Control Register

read/write

XYB

3

Modem Control Register

read/write

XYC

4

Line Status Register

read

XYD

5

Modem Status Register

read

XYE

6

The following pages describe the functions of each register on the serial adapter and on the GPIB-
COM. For a more complete description of the serial adapter, refer to the IBM Options and
Adapters Manual.
