Figure 6-2. Data Memory Map
Note Memory bank 0 or 1 can be selected as the stack area.
(32 Ч 4)
256 Ч 4
(224 Ч 4)
128 Ч 4
0
1
15
000H
01FH
020H
0FFH
100H
1E0H
1DFH
1F7H
1F8H
F80H
FFFH
General-purpose register area
Display data memory
Data area
static RAM
(512 × 4)
Stack area Note
Peripheral hardware area
Data memory Memory bank
Not incorporated
1FFH
256 Ч 4
(224 Ч 4)
(24 Ч 4)
(8 Ч 4)
