Napoleon Grills LD485RB - Manual (Page 32)

32
www.napoleongrills.com
Item Part # Description 485RB
1 N135-0038G lid side casting left x
2 N135-0039G lid side casting right x
3 N335-0050 stainless steel lid insert x
4 N585-0066 lid heat shield x
5 N510-0010 black silicone lid bumper x
6 N685-0006 temperature gauge x
7 N385-0129 NAPOLEON logo x
8 W450-0005 logo spring clips x
9 N010-0652 lid handle x
10 N080-0252G lid handle cover x
11 N570-0015 lid pivot screw x
12 N570-0073 1/4-20 x 3/8" screw x
13 N735-0003 1/4" lockwasher x
14 N570-0080 #14 x 1/2" screw x
15 N570-0013 #8 x 5/8" screw x
16 N520-0028K warming rack x
17 N475-0270K base insert right x
18 N035-0101 base side right x
19 N570-0093 screw M4 x 8mm" x
20 N450-0032 M4 lock nut x
21 N035-0102K base insert rear x
22 N200-0093S rear corner cover base x
23 N570-0008 #8 x 1/2" screw x
24 N475-0269K base insert left x
25 N035-0100 base side left x
26 N475-0298 rotisserie mount x
27 N305-0063 cooking grids - cast iron x
N370-0597 cooking grids - stainless steel upgrade kit ac
28 N305-0057K sear plate x
29 N080-0250 main burner support x
30 N100-0036 main burner x
31 N215-0008 grease deflector base x
32 N010-0501-M08 drip pan x
33 N735-0001 insulated washer x
34 N570-0082 1/4-20 x 5/8" screw x
35 N010-0721-SV1SG side shelf x
36 N120-0020-GY0TX end cap side shelf x
37 N570-0076 #8 x 1/2" screw x
38 N380-0011B control knob x
39 N051-0006 control knob bezel x
40 N010-0718 manifold assembly c/w valves P
N010-0719 manifold assembly c/w valves n
41 N120-0011 end cap control panel left x
42 N585-0065 base heat shield x
43 N035-0103K base insert front x
44 N120-0012 end cap control panel right x
45 N325-0062 handle door x
46 N475-0292 control panel x
47 N655-0124-GY1SG front cabinet support x
Parts List
