22
www.napoleongrills.com
4 x N570-0082 (1/4-20 X 5/8”) 3/8”(10mm) 4 x N735-0001 (insulated washer)
12. Side Shelf Installation
Insert (4) 1/4 - 20 x 5/8” screws through the washers into the threaded holes in the side of the base; do not tighten all the
way. Slide the assembled side shelf over the screw heads and finish tightening.
