System Configuration Guide
UPS
Configuration
[Note]
- Be sure to manage the UPS via network with Network shutdown software. The UPS can
not be managed via serial port and USB port with Power Chute Plus software.
RJ-45
connector
Power
socket
2 connectors
Power cord
Network HUB
RJ-45
Power
socket
2 connectors
Power cord
Network HUB
Redundant configuration :
Non-Redundant configuration :
1st Edition August ’10
UPS :
APC Smart-UPS 1500VA RM 2U
APC Smart-UPS 3000VA RM 3U
APC Smart-UPS RT 5000VA 208V
w/ 208V to 120V 2U Step-Down Transformer
Option :
Network management Card
Software :
PowerChute Network Shutdown
Product List
connector
NEC Express5800/R320a-E4/M4
APC UPS (3000 or 5000VA)
Network management Card
Be sure to manage the UPS via network with Network shutdown software. The UPS can
not be managed via serial port and USB port with Power Chute Plus software.
APC UPS (1500VA)
Network management Card
APC UPS (1500VA)
Network management Card
Page 17 1st Edition August ’10
980 Watts / 1500 VA
2700 Watts / 3000 VA
3500 Watts / 5000 VA, 5U
Down Transformer
The card managing the UPS via network, 1X 100BASE-T
Management software managing the UPS via network
