System Configuration Guide
Network (LAN)
[Note]
- Be sure to connect four physical LAN interfaces to the network HUB. Each of two pairs
of 1000BASE-T on the CPU/IO module is redundant configuration.
- Be sure to install the network cards on the same PCI slot# of each CPU/IO module.
1000BASE-T :
N8804-007 2-channel 1000BASE-T controller set
Product List
Configuration
RJ-45
connector
4 connector
1000BASE-T :
2channel 1000BASE-T
Controller [N8804-007]
1 logical slot
PCI-Ex Slot
1st Edition August ’10
NEC Express5800/R320a-E4/M4
Be sure to connect four physical LAN interfaces to the network HUB. Each of two pairs
T on the CPU/IO module is redundant configuration.
Be sure to install the network cards on the same PCI slot# of each CPU/IO module.
T controller set a pair of controller
1000BASE-T Network
Page 13 1st Edition August ’10
