Connecting Cables and Setting Switches
This section takes you through all the connections and switch settings necessary on the
motherboard. This will include:
• Power Connections
➢ 24-pin ATX Power (PWR1)
➢ 8-pin ATX 12V power (PWR2)
➢ Auxiliary power for graphics (PWR3)
• Internal Headers
➢ Front panel
➢ IEEE 1394a (FireWire)
➢ USB (Universal Serial Bus)
➢ Front Panel Audio
➢ Fan Connections
➢ Serial (COM)
• FDD Connector
• IDE Connector
• Serial ATA II Connectors
• Expansion Slots
• CMOS Jumper Settings
See Figure 1 on page 9 to locate the connectors and jumpers referenced in the
following procedure.
15
Hardware Installation
