37
www.napoleongrills.com
Item Part # Description RSIB
39 N051-0006 control knob bezel x
40 N530-0003 1-outlet regulator p
N345-0001 10ft n/g hose c/w quick disconnect n
41 N010-0716 manifold assembly c/w valves p
N010-0717 manifold assembly c/w valves n
42 N720-0044 manifold flex connector x
43 N255-0027 union fitting 3/8” - 3/8” x
44 N340-0007 tool hook x
45 N380-0019 control knob x
N720-0053 rear burner supply tube x
46 N051-0008 control knob bezel x
N720-0055 side burner supply tube x
47 N475-0183-GY1SG left/right side panel cabinet enclosure x
48 N160-0022 clip door pivot pin x
49 N475-0293-M06 door panel x
50 N325-0062 door handle x
51 N570-0073 1/4-20 x 3/8” screw x
52 N590-0147-GY1SG bottom shelf x
53 N655-0124-GY1SG front cabinet support x
54 N475-0271-GY1SG rear cart panel x
55 N585-0064P heat shield x
56 N105-0013 bushing x
57 N105-0011 door bushings x
58 N655-0094P tank ring support p
59 N430-0002 magnetic catch x
N370-0636 main assembly blister pack x
60 N080-0210 magnet bracket x
61 N750-0021B wiring harness led x
62 N190-0001 battery pack x
W043-0002 battery “AA’ x
63 N080-0254S tank inhibitor bracket p
64 N735-0001 insulated washer x
65 N105-0001 bushing 7/8” x
66 N640-0001 hose retainer clip x
67 N160-0015 propane tank clip p
68 N130-0012 revolving caster x
69 N450-0027 locking nut 1/4-20 x
70 N080-0212P stabilizer brackets x
71 N590-0164 condiment basket x
72 N130-0013 non revolving caster x
73 N585-0078 heat shield lid x
74 N485-0009 side burner lid clip x
75 N335-0048-M06 side burner lid x
76 N010-0612 side burner infra red x
77 N305-0072 side burner grate x
78 N010-0618 side burner plate assembly x
Parts List
