Item Part # Description RSIB
1 N135-0042-GY1HT left side lid casting x
2 N385-0129 NAPOLEON logo x
3 W450-0005 logo spring clips x
4 N510-0010 black silicone lid bumper x
5 N685-0012 temperature gauge x
6 N080-0287-GY1HT lid casting cover x
7 N335-0042L stainless steel lid insert x
8 N570-0024 1/4-20 x 1/2” screw x
9 N010-0720 lid handle x
10 N135-0043-GY1HT right side lid casting x
11 N570-0015 lid pivot screw x
12 N010-0565 hood assembly x
13 N570-0008 #8 x 1/2” screw x
14 N570-0073 1/4-20 x 3/8” screw x
15 N735-0003 1/4” lockwasher x
16 N520-0023 warming rack x
17 N305-0063 cooking grids - cast iron x
N370-0597 cooking grids - wave stainless rod ac
18 N305-0057-M05 sear plate x
19 N010-0722 stainless steel side burner shelf - right x
20 N570-0076 #8 x 1/2” screw x
21 N570-0082 1/4-20 x 5/8” screw x
22 N010-0721-M06 stainless steel side shelf - left x
23 N120-0020-GY0TX LUXIDIO side shelf end cap x
24 N200-0090-M06 infra red rear burner cover x
25 N010-0526P infra red rear burner p
N010-0526N infra red rear burner n
N455-0054 rear burner orifice #59 p
N455-0053 rear burner orifice #53 n
N720-0053 rear burner supply tube x
N160-0017 clip rear burner tube x
26 N240-0024P rear burner electrode c/w pilot p
N240-0024N rear burner electrode c/w pilot n
27 N080-0206 rear burner electrode cover x
28 N570-0079 rear burner electrode cover screw x
N615-0011 rear burner electrode cover spacer x
29 N100-0036 main burner x
30 N080-0281 main burner cross light bracket x
31 N475-0199-M06 rotisserie mount x
32 N010-0724 base x
33 N010-0501-M08 drip pan x
34 N160-0014 grease tray holder x
35 N185-0001 replacement grease tray aluminium x
36 N200-0089P back cover x
37 N475-0291CT control panel x
38 N380-0011 control knob x
Parts List
Item Part # Description RSIB
39 N051-0006 control knob bezel x
40 N530-0003 1-outlet regulator p
N345-0001 10ft n/g hose c/w quick disconnect n
41 N010-0716 manifold assembly c/w valves p
N010-0717 manifold assembly c/w valves n
42 N720-0044 manifold flex connector x
43 N255-0027 union fitting 3/8” - 3/8” x
44 N340-0007 tool hook x
45 N380-0019 control knob x
N720-0053 rear burner supply tube x
46 N051-0008 control knob bezel x
N720-0055 side burner supply tube x
47 N475-0183-GY1SG left/right side panel cabinet enclosure x
48 N160-0022 clip door pivot pin x
49 N475-0293-M06 door panel x
50 N325-0062 door handle x
51 N570-0073 1/4-20 x 3/8” screw x
52 N590-0147-GY1SG bottom shelf x
53 N655-0124-GY1SG front cabinet support x
54 N475-0271-GY1SG rear cart panel x
55 N585-0064P heat shield x
56 N105-0013 bushing x
57 N105-0011 door bushings x
58 N655-0094P tank ring support p
59 N430-0002 magnetic catch x
N370-0636 main assembly blister pack x
60 N080-0210 magnet bracket x
61 N750-0021B wiring harness led x
62 N190-0001 battery pack x
W043-0002 battery “AA’ x
63 N080-0254S tank inhibitor bracket p
64 N735-0001 insulated washer x
65 N105-0001 bushing 7/8” x
66 N640-0001 hose retainer clip x
67 N160-0015 propane tank clip p
68 N130-0012 revolving caster x
69 N450-0027 locking nut 1/4-20 x
70 N080-0212P stabilizer brackets x
71 N590-0164 condiment basket x
72 N130-0013 non revolving caster x
73 N585-0078 heat shield lid x
74 N485-0009 side burner lid clip x
75 N335-0048-M06 side burner lid x
76 N010-0612 side burner infra red x
77 N305-0072 side burner grate x
78 N010-0618 side burner plate assembly x
