Connections, Wiring diagram, English – NEC LCD4215 User Manual

Page 15: Before making connections

English-13

English

Connections

Before making connections:

First turn off the power of all the attached equipment and make connections.

Refer to the user manual included with each separate piece of equipment.

Wiring Diagram

Personal computer

BNC x 5

BNC x 3

RCA

To DVI output

Mini D-sub 15 pin

To DVD Component

video output

DVD player

To audio output

BNC-to-RCA

adapter BNC x 3

To audio output

VCR

To composite Output

In case of VCR

DVI-D connector

To audio output

Equipment with
digital Interface

To analog RGB output
