Each setting represents one synchronous data rate and one asynchro-
nous data rate.
Note If the S2-1 switch is positioned in the OFF position, the 128 kbps
sync data rate/0–38.4 kbps async data rate option is selected.
Switch S1-3: Must be set to the ON position (Reserved) .
Switch S1-4: Must be set to the ON position (Reserved).
Switch S1-5: Asynchronous/Sync Operation. Use Switch S1-5 to
configure the Model 1053 for async/sync operation. For synchronous
data rates set switch S1-5 OFF. For asynchronous rates set switch
S1-5 ON.
Switches S1-6 and S1-7: System Clock Mode. Use Switches S1-6
and S1-7 to configure the 1053 for internal, or receive recover clock
mode.
S1-1 S1-2 Sync Data Rate Async. Data Rate
On On 128 kbps 115.2 kbps
Off On 64 kbps 57.6 kbps
On Off 56 kbps 76.8 kbps
Off Off 32 kbps 0–38.4 kbps
S1-3 Setting
On Reserved
S1-4 Setting
On Reserved
S1-5 Setting
Off Sync
On Async
S1-6 S1-7 Clock Mode Description
On On Internal System clock generated internally
Off On External (DTE) System clock derived from termi-
nal interface
On Off Receive Recover System clock derived from the
received line signal
Off Off Hardware Reset
