Jazzy 1103 Ultra www.pridemobility.com 19
JAZZY 1103 ULTRA SPECIFICATIONS
Suspension: Active Trac
Drive Wheels: 10 in. (25.4 cm) pneumatic or solid available
Caster Wheels: 8 in. (20.32 cm) solid, rear-mounted
Anti-tip Wheels: 5 in. (12.7 cm) solid, front-mounted
Maximum Speed:¹ Up to 4 mph (6.43 km/h)
Range:¹ Up to 25 miles (40 km)
Brakes: “Intelligent Braking” electronic regenerative, disc park brake
Ground Clearance:² 2.5 in. (6.35 cm)
Turning Radius:² 20.75 in. (52.7 cm)
Overall Size:² Length: 35.5 in. (90.17 cm)
Width: 23 in. (58.42 cm)
Drivetrain: Two motor, mid-wheel drive
Batteries:³ Two 12-volt, deep-cycle, U-1 batteries
Battery Charger: 4-amp, onboard (standard)
Off-board (optional)
Weight Capacity: 300 lbs. (136 kg)
200 lbs. (90.72 kg) with TRU-Balance Power Positioning Systems
160 lbs. (72.57 kg) with Synergy Manual Tilt
Component Weights: Base: 104 lbs. (47.17 kg)
Standard Seat: 37 lbs. (16.78 kg)
Batteries: 24.5 lbs. (11.11 kg) each
I I I . Y O U R P O W E R C H A I R
¹ Varies with base model, user weight, terrain type, battery amp-hour rating (Ah), battery charge, battery condition,
motors, controller type, tire type, and tire condition.
² Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance of
(+ or – ) 3%.
³ AGM or Gel-Cell type required. See VI. “Batteries and Charging.”
NOTE: All specifications subject to change without notice.
