Jazzy 1103 Ultra
I I I . Y O U R P O W E R C H A I R
THE JAZZY 1103 ULTRA
The Jazzy 1103 Ultra has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the seat
assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake assemblies,
two drive wheels, two anti-tip wheels, two caster wheels, two batteries, and the electrical components.
SEATBACK
CONTROLLER
(VSI SHOWN)
REAR
SHROUD
ANTI-TIP WHEEL
DRIVE WHEEL
CASTER WHEEL
Figure 5. The Jazzy 1103 Ultra
JOYSTICK
FOOT PLATFORM
SEAT BASE
ARMRESTS
FRICTION LOCK LEVER
SEATBACK
RELEASE LEVER
SEAT ASSEMBLY
POWER BASE
ASSEMBLY
