Planar PL1500M - Manual (Page 8)

5
Set-up Instructions
Making the Connections
Note:
Place the monitor on a flat, sturdy surface. Select an area free from
excessive heat, moisture, and sunlight.
Before connecting any cables, make sure that both the computer and monitor are
turned off.
1.
Connect the AC power adapter with the power cord.
2. Connect the power cord to the power jack on the back of the monitor (as shown
below).
3.
Plug the power cord into a power outlet, and plug the other end into the AC
power adapter.
4.
Plug the analog video signal cable into the Analog Video Input port on the back
of the monitor (as shown above).
5.
Connect the other end of the video signal cable into your computer’s video port.
(Please check your computer’s documentation if you’re not sure where the port
is located.)
6.
Plug the audio signal cable to the Audio port on the back of the monitor;
connect the other end of audio signal cable to your computer’s audio port.
