17
Video Modes
The monitor supports the following industry-standard combinations of screen
resolution and refresh rates. Other combinations are possible, but may require
adjustments to the image.
For the optimal performance, set your computer to a screen resolution of 1024 x 768
at a 60 Hz refresh rate.
Display Mode Hsync (kHz) Vsync (Hz) Dot Frequency (MHz)
640 x 350 31.5 70 25.175
31.5 60 25.175
37.9 72 31.5
37.5 75 31.5
VGA
640 x 480
35.0 70 28.56
35.1 56 36.0
37.9 60 40.0
48.1 72 50.0
46.9 75 49.5
SVGA 800 x 600
43.75 70 45.5
48.4 60 65.0
56.5 70 75.0
60.0 75 78.75
XGA 1024 x 768
57.672 72 78.434
US TEXT 720 x 400 31.5 70 28.3
640 x 480 35.0 67 30.5
Power
MAC
832 x 624 49.7 75 57.3
Note:
The monitor is capable of going beyond these recommended modes.
Setting the Video Mode
Since the inherent format of this display is 1024 pixels by 768 lines, the monitor will
perform best when your computer is set to a screen resolution of 1024 x 768. If you
use a lower resolution (such as 640 x 480), the image is expanded to fill the screen.
Your display supports many common video modes, as shown in “Video Modes” on
page 17. Check the documentation supplied with your computer and video adapter
card to find out which modes they support.
To see what video mode is in use within Microsoft Windows, please check Windows’
settings in your computer.
