FXS ports
60
SmartNode 4400 Series Getting Started Guide
C • Port pin-outs
Yellow
Brown
Tip 19
Pair 19
44
Brown
Yellow
Ring 19
19
Yellow
Slate
Tip 20
Pair 20
45
Slate
Yellow
Ring 20
20
Violet
Blue
Tip 21
Pair 21
46
Blue
Violet
Ring 21
21
Violet
Orange
Tip 22
Pair 22
47
Orange
Violet
Ring 22
22
Violet
Green
Tip 23
Pair 23
48
Green
Violet
Ring 23
23
Violet
Brown
Tip 24
Pair 24
44
Brown
Violet
Ring 24
24
Violet
Slate
Tip 25
Pair 25
50
Slate
Violet
Ring 25
25
Table 11. Band marked color-codes for the
50-pin RJ-21X connector (Continued)
Wire/Color Code
Tip & Ring
Pair Number
50 Pin
Positions
Main color
Stripe
