Introduction 35
SmartNode 4400 Series Getting Started Guide 4 • Getting started with the SmartNode 4400 Series
Introduction
This chapter leads you through the basic steps to set up a new SmartNode and to download a configuration.
Setting up a new SmartNode consists of the following main steps:
Note If you have not already installed the SmartNode, refer to chapter 3,
“Hardware installation” on page 23.
1. Configuring the desired IP address (see figure 14 ). Refer to section “2. Connecting the SmartNode to
the network” on page 39 for details.
Figure 14. Connecting the SmartNode to your laptop PC
2. Connecting the SmartNode to the network (see figure 15 ). Refer to section “1. Configure IP address” on
page 36 for details).
Figure 15. Connecting the SmartNode to the network
Console port
Laptop PC
Model 16F-561
adapter and cable
100-240V
(50-60 Hz) 1 AMP
UNIT EQ UIPPED WITH DU AL S UPPLIES
DISCONNECT BO
TH SUPPLIES
BEFORE SER VICING
ETH 0/0
Console
Telco P or ts
50
Reset
ETH 0/1
100-240V
(50-60 Hz) 1 AMP
UNIT EQ UIPPED WITH DU AL SUPPLIES
DISCONNECT BO
TH SUPPLIES
BEFORE SER VICING
ETH 0/0
Console
Telco P or ts
50
Reset
ETH 0/1
LAN (ETH 0/1) Network
interface
PC or workstation
or Telnet
LAN
Internet or
WAN (optional)
WAN
(ETH 0/0)
