MAINFRAME PARTS LIST

PART #.

QTY.

KEY #.

DESCRIPTION

A

1

71751015

LOWER MAIN FRAME

B

1

71751018

REAR LEG

C

1

71751017

REAR UPRIGHT

D

1

71751014

UPPER MAIN FRAME

E

1

71751016

REAR UPPER BEAM

F

2

70566104

WEIGHT STACK RISER

G

2

70566008

GUIDE ROD

H

1

71751008

FUNCTION TRAINING ARM

J

1

70566007

FRONT FOOT PLATE

K

1

70566103

LEG EXTENSION ARM

L

1

70566013

SEAT PAD FRAME

M

1

70566012

BACK PAD FRAME

N

1

70566011

BACK PAD ADJUSTMENT

P

1

70566067

STABILIZING LEG

Q

1

71751019

PRESS ARM PIVOT

R

1

70566020

PRESS ARM

S

1

70566021

RIGHT HANDLE

T

1

70566022

LEFT HANDLE

U

1

70566026

PRESS ARM PULLEY COVER

V

1

70566014

UPPER FLOATING PULLEY BRACKET

W

1

70566015

AB CRUNCH PULLEY BRACKET

X

1

70566028

LAT BAR

Y

1

71101040

LOW ROW BAR

AA

2

70566027

BACK/SEAT PAD

AB

2

70544022

FLOATING PULLEY BRACKET

AC

1

71751002

PULLEY BRACKET ASSEMBLY

AD

1

71751006

PULLEY BRACKET

AE

2

71751009

FUNCTIONAL TRAINING ARM PULLEY BRACKET

AF

1

71751001

DOUBLE PULLEY BRACKET

AG

2

71751011

METAL SPACER
