Protected MasterColor
®
Metal Halide 150 Watt ED-17P
4K (Coated) Lamp Featuring ALTO
®
Lamp Technology
■
Ordering Information
Ordering Code
MHC150/C/U/MP/4K/ALTO
ANSI Designation M102/M142
/O
Product Number
377267
Description
MasterColor Metal Halide
Package Quantity
12
■
Physical Characteristics
Bulb Size
ED-17P
Bulb Finish
Phosphor-Coated
Base
Medium-Screw
Max. Overall Length (MOL)
5 7/16'' (138mm)
Light Center Length (LCL)
3 7/16'' (87mm)
Arc Length
0.79'' (20mm)
Arc Tube Material
Poly Crystalline Alumina
Max. Permissible Bulb Temp.
400º C (752º F)
Max. Permissible Base Temp.
190º C (374º F)
Max. Bulb to Base Eccentricity
3º
Max. Arc Tube to Base Eccentricity
3º
■
Operating Characteristics (Photometric)
Rated Initial Lumens
(1)
11,
000
Mean Lumens, Approx.
(2)
8250
Rated Average Life, Hours
20,000
Correlated Color Temp. (CCT)
(2)
4000K
CIE Chromaticity Approx.
(2)
x-.3
88, y-.374
Color Rendering Index (CRI)
92
Efficacy (lpw) 7
3
■
Operating Position
Universal–Open or Enclosed Luminaires
Note: Electronic ballasts are preferred for optimum performance,
energy efficiency and circuit loading.
MasterColor® Spectral Power Distribution—4K Types
RELA
TIVE ENERGY
400
450
500
550
600
650
700
WAVELENGTH (Nanometers)
350
300
250
200
150
100
50
0
(Provisional Data*)
