2002 Oct 18 12
Philips Semiconductors Product specification
Triple video output amplifier TDA6107JF
TEST AND APPLICATION INFORMATION
handbook, full pagewidth
MBL526
2 M
Ω
C1
1
9
1
J1
22 µ F
22 nF
C2
4
probe 1
R1
100 k Ω
R2
6.8 pF
C10
20 nF
C7
10 µ F
C8
3.2 pF
C9
136 pF
C11
VIP
REFERENCE
Vi(1)
Vof
Iom
Voc(1)
VDD
Ri
Rf
Ra
2 M Ω
C3
2
6
8
2
J2
22 µ F
22 nF
C4
probe 2
R3
100 k Ω
R4
6.8 pF
C13
3.2 pF
C12
136 pF
C14
Vi(2)
Vof
Iom
Voc(2)
Ri
Rf
Ra
2 M
Ω
C5
TDA6107JF
3
7
5
3
J3
22 µ F
22 nF
C6
probe 3
R5
100 k Ω
R6
4 V
6.8 pF
C16
3.2 pF
C15
136 pF
C17
Vi(3)
Vof
Iom
Vo(m)
Voc(3)
Ri
Rf
Ra
Fig.8 Test circuit.
Current sources J1, J2 and J3 are to be tuned so that V
o(c)
of pins 9, 8 and 7 is set to 100 V.
